Shelly Wi-Fi Plus 1 with Dry Contacts

Add Wi-Fi Connectivity To Connected Lights And Appliances

Add Wi-Fi control to a wide range of office equipment or home appliances with the Shelly Wi-Fi Plus 1 with Dry Contacts. This Wi-Fi smart switch is designed for installing behind a wall switch or electrical outlet to add Wi-Fi remote control to a wide range of applications such as lights, irrigation systems, heating and cooling systems, security devices, radiators, and more. It features 1 switch/button input, 1 potential-free contacts relay input, 3 power supply inputs, and 1 potential-free contacts relay output and is compatible with various load types, such as resistive loads (incandescent bulbs and heating devices), capacitive loads (capacitor banks, electronic equipment, and motor start capacitors), and inductive loads with RC Snubber (LED light drivers, transformers, fans, refrigerators, and air conditioners).

The Shelly Wi-Fi Plus 1 can be remotely accessed, controlled, and monitored from anywhere with an Internet connection using the Shelly Smart Control App (for iOS and Android) – as long as the Plus 1 is connected to a Wi-Fi router and the Internet. You'll be able to use your smartphone, tablet, PC, or home automation system to control the connected light or appliance and add them to smart home automation scenes. When paired with other smart devices in your smart home network, you trigger your lights to turn on when someone enters a room or have the lights turned off when motion is not detected for a predetermined amount of time. It's even compatible with voice assistants and other home automation platforms such as Amazon Alexa, Google Assistant, and Samsung SmartThings for easy voice commands and smart control.

• Adds Wi-Fi functionality to connected devices by installing behind wall outlets and light switches
• Connects effortlessly to your Wi-Fi network and offers Bluetooth connectivity for quick set up – no smart hub required
• Ideal for lights, garage doors, irrigation systems, bathroom fans, or any old electrical appliances
• Smartphone control via the Shelley Smart Control App (for iOS or Android) or through your home automation system's app
• Set custom schedules based on daily routine or follow sunrise/sunset to automatically control your lighting
• Extremely fast processor with ESP32 microcontroller and improved API interface
• Compatible with voice assistants and other automation platforms such as Alexa, Google Assistant, and Samsung SmartThings

Shelly Smart Control App – Everything at Home Connected

Enjoy enhanced home automation control and precise monitoring of your Shelly devices no matter where you are with the Shelly Smart Control app. The app connects to Shelly's cloud service to help you control your connected devices remotely and send notifications for all automated events in your home directly to your smart device. You can easily configure devices and manage their settings individually, or you can create personalized scenes by combining Shelly devices to trigger certain actions in your home automation. The Shelly Smart Control App supports real-time power metering with power management (PM) devices, smart plugs, and smart bulbs in order to allow you to build complex automation solutions for improved energy efficiency and lower electricity bills.

• Easy Inclusion and Control: Include and name new devices in the Shelly Smart Control app, assign them to the rooms they are located in, and group them into scheduled or automated scenes.
• Custom Dashboard: Create multiple dashboards for quick access to your preferred devices, rooms, and scenes. Issue commands using your dashboards or your preferred voice assistant towards individual devices or a group of devices.
• Smart Scenes: Combine multiple devices into one smart scene with pre-set triggered actions. Lower the lights when the TV is turned on for a "Movie night". Cut off the power and send a notification when a space heater has been left on past 9am while you are "Away at Work".
• Custom Schedules and Timers: Teach your home how to make you more comfortable by setting custom schedules based on your agenda. You can set a Shelly controlled switch to turn on the outdoor lights at 7:00 PM on workdays, or turn on your heater an hour before you return from work.
• Energy Monitoring: An energy consumption panel gives you a detailed view of your live and recorded energy usage from devices controlled by Shelly Qubino products. The information is stored in a free cloud and fully accessible to you for further analysis of your energy consumption habits.
• Works with Alexa: The Shelly Smart Control app is natively compatible with Amazon Alexa.

Contents

• Plus 1 Smart Switch
• Manual

NOTE: Requires connection to a Wi-Fi network.

Shelly Qubino Provides A 100% Wireless Smart Home

Shelly Qubino creates innovative and affordable smart home devices for residential and business applications. Qubino, now owned by Shelly, focuses on providing Z-Wave compatible smart home solutions. Shelly Qubino devices are among the smallest Z-Wave devices in the world, allowing them to find their place in nearly any sized smart home installation. Shelly Qubino utilizes the latest Z-Wave technologies to deliver superior automation, safety, and energy efficiency to their customers without breaking down their walls or bank accounts.

• Manufacturer Part #: Plus 1-1 UL
• EAN: 3800235265000
• Power Supply: 110 – 240 VAC / 24 – 48 VDC / 12 VDC ±10%
• Power Consumption: <1.2 W
• Max. Switching Voltage AC: 240 VAC
• Max. Switching Voltage DC: 30 VAC
• Max. Switching Current AC: 16 A
• Max. Switching Current DC: 10 A
• Internal-Temperature Sensor: Yes
• Wi-Fi Protocol: 802.11 b/g/n
• RF Band: 2400 – 2495 MHz
• Max. RF Power: <20 dBm
• Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
• Bluetooth Protocol: 4.2
• RF Band: 2400 – 2495 MHz
• Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
• CPU: ESP32-U4WDH
• Flash: 4 MB
• Schedules: 20
• Webhooks (URL actions): 20 with 5 URLs per hook
• MQTT: Yes
• Scripting: Yes
• CoAP: No
• Screw Terminals Max Torque: 0.4 Nm / 3.5 lb/in
• Conductor Cross Section: 0.5 to 1.5 mm² / 20 to 16 AWG
• Conductor Stripped Length: 5 to 6 mm / 0.20 to 0.24 in
• Mounting: Wall Console
• Color: Blue
• Shell Material: Plastic
• Ambient Temperature: -5 °F to 105 °F (-20 °C to 40 °C)
• Humidity: 30% to 70% RH
• Max Altitude: 2000 m / 6562 ft
• Size (HxWxD): 1.46 x 1.65 x 0.63 ±0.02 in inches (37 x 42 x 16 ±0.5 mm)
• Weight: 26 g / 0.92 oz
• Warranty: 3 Year

»Shelly Plus 1 Wi-Fi Smart Switch with Potential-Free Contacts User Manual (.pdf)
