2GIG E+ Passive Infrared Motion Detector

Motion Sensor With Extended Wireless Range & Pet Immunity

Add better security to monitor what's happening in your home or office with the 2GIG E+ Passive Infrared Motion Detector. This motion sensor accurately detects motion within a 30 by 50 feet range and is specifically designed with pet immunity to filter out movements of pets weighing up to 85 pounds, which minimizes false alarms. As part of 2GIG's E+ series of extended range sensors, it operates on the 900 MHz spectrum, giving it an operation range of up to 1.2 miles. It also features two-way encrypted communication for added security, includes installer-adjustable settings for pet immunity on/off, and has a battery life of up to 3 years for long-lasting use.

• Monitors movement in a room with a detection range of 30 by 50 feet
• Pet immunity filters out movements of pets weighing up to 85 pounds to minimize false alarms
• Operates on the 900 MHz spectrum with an extended range of up to 1.2 miles
• Enhanced security with two-way encryption prevents unauthorized access
• Works with 2GIG EDGE Panel (FW 1.3 or later is required)

E+ Extended Range Sensors by 2GIG

2GIG E+ Extended Range Sensors work on the 900MHz spectrum to provide expanded security coverage for larger residential and commercial properties. With sleek, modern sensor designs that complement just about any decor or aesthetic, the E+ series includes indoor and outdoor contact sensors, as well as motion, glass break, and smoke detectors. When integrated with the advanced 2GIG EDGE panel, these sensors boost security with reliable functionality and better protection at home or at the office.

Contents

• Passive Infrared Motion Detector
• Instruction Manual

Innovation Drives 2GIG Technology

Now a member of NICE's family brands, 2GIG offers intuitive and creative home automation and smart security technologies. Their premium security and home automation security panels, thermostats, and security sensors provide reliable and easy to use solutions to improve your home living or routine business days. 2GIG's has become a leading name in Z-Wave wireless systems, and has won numerous industry awards since 2011. With 2GIG in control, users experience cutting edge technology to make their homes smarter, safer, and more efficient. 2GIG offers intuitive and creative home technology with its premier self-contained, all-in-one security and home automation system. 2GIG's GoControl system has become a leading control hub for Z-Wave wireless systems, has won numerous industry awards, including TechHome's 2011 Security Product of the Year and the 2012 Overall Maximum Impact Award at Electronic Security Expo (ESX). With 2GIG in control, users experience technology they never thought possible.

• Manufacturer Part #: 2GIG-PIR1E-900
• UPC: 093863149559
• Transmitter Frequency: 904MHz ~ 922MHz
• Compatibility: 2GIG EDGE Panel (FW 1.3 or later is required)
• Code Outputs: Alarm, Alarm Restore, Tamper, Tamper Restore, Supervisory, Low Battery
• Supervisory Interval: 70 Minutes
• Sensor Type: Quad Element
• Pet Immunity: Up to 85 lbs (38 kg)
• Suggested Mounting Height: 7.5 ft. (2.3 m)
• Sensor Range: 30 ft. (9.1m) x 50 ft. (15.2 m)
• Horizontal Sensing Angle: 100° Maximum Spread
• Dimensions: (L x W x H) 3.53" x 2.35" x 1.63" (5.4 x 6 x 4.1 cm)
• Weight: 3.5 oz (98 g)
• Housing Material: ABS Plastic
• Operating Temperature: 32°-120°F (0°-49°C)
• Relative Humidity: 5% to 90%, Non-condensing
• Battery (Included): One CR123A 3V or equivalent Lithium Battery
• Certifications: ETL, FCC, and IC

»2GIG E+ Series 2GIG-PIR1E-900 Passive Infrared Motion Detector Spec Sheet (.pdf)
