Shelly Qubino Wave Plug, Z-Wave 800 Smart Wall Plug
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Details
Make Any Plug-In Light or Appliance Smart
Turn any plug-in lamp or appliance into a remote controlled smart home device with the Shelly Qubino Wave Plug, Z-Wave 800 Smart Wall Plug! This smart plug adds Z-Wave automation features, energy monitoring, and remote control to any device plugged into it, which gives you more convenient control over your chosen device. From the Shelly Smart Control app, you can turn the Wave Plug US and its controlled device On/Off on demand or according to a preset schedule or automated routine. If the Wave Plug US is plugged into an outlet controlled by a local switch, the switch can also turn the Wave Plug US On and Off. The Wave Plug US can handle power usage of up to 1800W @ 15A to allow you to include your TV, lampstand, portable fan, space heater or single room AC units into your Z-Wave compatible smart home network.
- Z-Wave smart plug adds Z-Wave functionality and energy monitoring to a single plug-in device
- Supports devices using up to 1800W@15A including TVs, portable fans, space heaters, portable AC units, high wattage lamps, and more
- Monitors and records energy consumption of a plugged-in device to assist in tracking activity status and optimize energy usage
- Built-in surge protection and overheat protection ensures the safety of the Plug and plugged-in device
- Can be included in Z-Wave automated scenes and schedules to turn On/Off according to preset triggers, timers, or time of day
- Standard Z-Wave mesh protocol range reaches up to 130 feet (40m) line of sight to the nearest Z-Wave receiver or hub
- Z-Wave 800 software provide increased power, longer range, faster transmissions, and improved security
- Z-Wave Smart Start technology pairs news devices quickly and S2 framework ensures enhanced security
- Compatible with leading Z-Wave compatible brands including Fibaro, Google Home Assistant, HomeSeer, SmartThings, Vera, Zipato, and more!
Shelley Smart Control App – Everything at Home Connected
Enjoy enhanced home automation control and precise monitoring of your Shelly devices no matter where you are with the Shelly Smart Control app. The app connects to Shelly's cloud service to help you control your connected devices remotely and send notifications for all automated events in your home directly to your smart device. You can easily configure devices and manage their settings individually, or you can create personalized scenes by combining Shelly devices to trigger certain actions in your home automation. The Shelly Smart Control App supports real-time power metering with power management (PM) devices, smart plugs, and smart bulbs in order to allow you to build complex automation solutions for improved energy efficiency and lower electricity bills.
- Easy Inclusion and Control: Include and name new devices in the Shelly Smart Control app, assign them to the rooms they are located in, and group them into scheduled or automated scenes.
- Custom Dashboard: Create multiple dashboards for quick access to your preferred devices, rooms, and scenes. Issue commands using your dashboards or your preferred voice assistant towards individual devices or a group of devices.
- Smart Scenes: Combine multiple devices into one smart scene with pre-set triggered actions. Lower the lights when the TV is turned on for a "Movie night". Cut off the power and send a notification when a space heater has been left on past 9am while you are "Away at Work".
- Custom Schedules and Timers: Teach your home how to make you more comfortable by setting custom schedules based on your agenda. You can set a Shelly controlled switch to turn on the outdoor lights at 7:00 PM on workdays, or turn on your heater an hour before you return from work.
- Energy Monitoring: An energy consumption panel gives you a detailed view of your live and recorded energy usage from devices controlled by Shelley Qubino products. The information is stored in a free cloud and fully accessible to you for further analysis of your energy consumption habits.
- Works with Alexa: The Shelly Smart Control app is natively compatible with Amazon Alexa.
Installation Details
The Wave Plug US can be inserted into any standard US power outlet and allows for control over a single device. The Wave Plug US will automatically attempt to locate and request inclusion into your local Z-Wave network after it is plugged in. A power strip or extension cord should not be plugged into the Wave Plug. Once a device has been plugged in,the Wave Plug US can report its real time device status, as well as record and measure their energy consumption over time.
Z-Wave Plus v3 Certification
Z-Wave Plus v3 is an upgraded Z-Wave certification program to help you identify products that take advantage of the latest Z-Wave hardware platform, also known as 800 Series or Gen8 Z-Wave. Z-Wave Plus v3 compatible devices include extended wireless relay range up to 1300 ft/400m, three layers of encryption, faster operation, and longer battery life.
Contents
- Wave Plus US
- DSK Label
- Manual
NOTE: Z-Wave compatible gateway or system hub required, sold separately.
Shelley Qubino Provides A 100% Wireless Smart Home
Shelley Qubino creates innovative and affordable smart home devices for residential and business applications. Qubino, now owned by Shelley, focuses on providing Z-Wave compatible smart home solutions. Shelley Qubino devices are among the smallest Z-Wave devices in the world, allowing them to find their place in nearly any sized smart home installation. Shelley Qubino utilizes the latest Z-Wave technologies to deliver superior automation, safety, and energy efficiency to their customers without breaking down their walls or bank accounts.
Specifications
- Manufacturer Part #: Wave Plug US
- EAN: 3800235269060
- Power Supply: 120 V ±10%, 60 Hz
- Power Consumption: < 0.3 W
- Max. Switching Voltage AC: 140 V
- Max. Switching Current AC: 15 A
- Overheating Protection: Yes
- Overcurrent Protection: Yes
- Overvoltage Protection: Yes
- Distance: up to 40 m indoors (131 ft.) (Depends on local condition)
- Z-Wave Repeater: Yes
- CPU: Z-Wave S800
- Z-Wave Frequencies Band: 908.4 MHz
- Maximum Radio Frequency Power Transmitted in Frequency Bend(s): < 25 mW
- Size (H x W x D): 38 H x 84 W x 52 Dmm / 1.5 H x 3.3 W x 2.0 D in
- Weight: 70 ±1 g / 2.47 ±0.04 oz
- Compatible Sockets: NEMA 5-15 (Type-B)
- Compatible Plugs: NEMA 1-15 (Type-A) and NEMA 5-15 (Type-B)
- Shell Material: Plastic
- Color: White
- Ambient Temperature: -20°C to 40°C / -5°F to 105°F
- Humidity: 30% to 70% RH
- Max. Altitude: 2000 m / 6562 ft.
- Warranty: 2 Year
