Sensaphone FGD-0049-B Smoke Detector, Battery Back-Up, 110 VAC

For Use In Commercial & Residential Applications

The Smoke Detector with built-in relay utilizes a photoelectric sensing method and is designed for use in commercial and residential applications. The device requires hard-wired 120VAC 60Hz power. The detector features two sets of dry alarm contacts: one form-A SPST and one form-C SPDT. The detector has tandem interconnect capability allowing up to 6 devices to be connected together. A 90 dBA audible horn is included.

Contents

• Smoke Detector
• Wiring Harness
• Mounting Template
• Instruction Manual

IMPORTANT NOTE: This Sensaphone product is not available to ship outside the U.S.

Sensaphone Remote Monitoring Solutions

Unexpected events happen. But Sensaphone remote monitoring systems are on alert full time to notify you of threatening conditions, so you can respond quickly and prevent costly damages and disruptive downtime. From wireless capabilities to ultra-low temperature tolerant systems, you'll find the right Sensaphone for your monitoring needs. Start protecting your investments today.

• Manufacturer Part #: FGD-0049-B
• Dimensions: 6-1/2" diameter x 2-5/8"
• Housing: White plastic
• Operating Temp Range: 40° to 100° F (4° to 37° C)
• Compatibility: All Sensaphone models
• Warranty: 1 Year

»Sensaphone FGD-0049-B Smoke Detector Spec Sheet (.pdf)
