Speco 9-Port Gigabit Network Switch

SKU: SPP8S9G

Order now and we'll ship same business day (if ordered before 3 pm PST).

$248.61

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Details

Power And Connect Up To 9 PoE Devices

Power and connect up to 9 PoE/PSE devices using the Speco 9-Port Gigabit Network Switch. This Gigabit Ethernet switch delivers power and lightning fast data transfer speeds to up to 8 Ethernet-connected devices. This rack-mounting switch is designed to support medium-to-large data and/or surveillance networks and applications. Each PoE port handles up to 30 Watts of power (max.), with a total power budget of 120 Watts. In addition to its 8 PoE ports, the switch also includes one Gigabit SFP uplink port for easy expansion with new or existing network switches.

  • Gigabit network switch supports 9 PoE devices
  • CCTV mode isolates each port from one another for added security and performance
  • Max. 30W power per PoE/PSE port
  • Surge-Protection for each individual port

Contents

  • Network Switch

IMPORTANT NOTE: Speco Technologies products are not available to ship outside the U.S. Please contact Speco Technologies directly for international orders.

Commercial & Residential Solutions From Speco

Speco Technologies is dedicated to providing the highest quality residential and commercial sound, security, CCTV closed circuit video and electronic accessories. Contractors, installers, builders, engineers, architects and homeowners rely on Speco products to satisfy both their commercial and residential needs. Home Controls is an authorized Speco distributor, ensuring customers obtain proper support and service.

Specifications

  • Manufacturer Part #: P8S9G
  • Downlink Ports: 8 x 10/100/1000Base-T (PoE)
  • Uplink Ports: 1 x 10/100/1000BaseT & 1 x 1000Base-X SFP Port
  • PoE Standards: 802.3af/at (PSE)
  • Exchange Type: Storage & Forwarding
  • PoE Power Supply: 1/2(+), 3/6(-)
  • Ethernet Standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z
  • Packet Forwarding Rate: 14Mpps
  • Switch Capacity: 20GBps
  • MAC Address: 4K
  • PoE Output: Single port ≤ 30W (54V DC), Total for all ports ≤ 120W

Environmental

  • Operating Temperature: 14° to 131°F (-10° to 55.5°C)
  • Storage Temperature: -40° to 185°F (-40° to 85°C)
  • Operating Humidity (Non-Condensing): 5 to 95 percent RH

Mechanical

  • Dimensions: 7.9 inches (L) x 4 inches (W) x 1 inches (H)
  • Weight: 1.1 pounds

Protection Level

  • ESD: Contact Discharge 6K, Air Discharge; 8KV, Per: IEC61000-4-2
  • Surge Protection: 6KV, Per: IEC 61000- 4- 5
  • Warranty: 2 Years
