SkylinkNet Security Keypad


Order now and we'll ship same business day (if ordered before 3 pm PST).


WARNING: Cancer and Reproductive Harm –


Indoor Keypad to Arm/Disarm

Perfect for a garage or back door, the SkylinkNet Security Keypad provides convenient security system control at a secondary location in your home. Keep the main console in one area and install the keypad in another. Anytime you press a button, the keypad lights up for ease of use. After punching in your passcode (optional), you can set the system mode to Arm Away, Arm Home, Disarm, or Panic.

  • Indoor keypad for Skylink security systems
  • Arm Away, Arm Home, Disarm, and Panic
  • Backlit buttons for easy nighttime use
  • Wireless range up to 600 feet
  • Optional password protection
  • Works with SkylinkNet and M-Series systems

When enabled, optional password protection prevents unauthorized use. The remote will only operate once you input the correct password. Your password can be 2 to 8 digits long with a combination of buttons from 0-6.

Compatibility & Installation

The SkylinkNet Security Keypad is compatible with either the Skylink Internet Hub (HU-100) or the M-Series Main Console (M-1), sold separately. It mounts to a wall with the included screws.


  • Security Keypad
  • Screws
  • User Manual

NOTE: Requires one (1) AAA battery, not included. Not rated for outdoor use. Up to four keychain remotes/keypads total can be programmed into one zone.

IMPORTANT NOTE: Skylink products are not available to ship outside the U.S. Please contact Skylink directly for international orders.

The Skylink Group

The Skylink Group understands the needs and concerns of homeowners in providing a safe haven and comfortable environment for their families. The group offers a comprehensive range of products to meet all home operation and security needs, including wireless alarm systems, emergency dialers, motion detector sets, sensors and alert mechanisms. The group has been manufacturing electronics for over 30 years, and continues to enhance features and test technology on an ongoing basis to ensure reliability.


  • Manufacturer Part #: KN-MT
  • Battery: 1 x AAA Alkaline Battery (Not Supplied)
  • Battery Life: Approx. 24 months (Typical)
  • Operation Range: 600 feet (180 meters)
  • Radio Frequency: Skylink M-Code 433.92MHz
  • Size: 4.5(L) x 2.25(W) x 0.75(H) inches
  • Weight: 100g
  • Housing Material: ABS plastic
  • Color: Off-White
  • Operating/Storage Conditions:
    • Temperature: -22 to 140 degrees F (-30 to -60 degrees C)
    • Humidity: 20 to 90 percent
  • Compatibility: Internet Hub, HU-100; Main Console, M-1
  • Approvals: FCC, CE, IC
  • Warranty: 1 Year
