On-Q/Legrand Quick Connect Cat6a RJ45 Keystone Snap-In Connector

Cat6a Cable Connector

The On-Q/Legrand Quick Connect Cat6a RJ45 Keystone Connector is used with Cat6 cables and exceeds EIA/TIA 568A/B Cat6a performance specifications. Connections can be terminated with any 110 punchdown tool. Use the Legrand AC3400 Punch and Go Tool (sold separately) to easily terminate all four pairs.

Start With A Strong Foundation

From innovative enclosures to high-performance connection outlets, On-Q products guarantee a smooth installation. Your home is a refuge from the world, a sanctuary from the elements, a place you can relax in comfort. Maximize your home living experience with innovative solutions from On-Q/Legrand. Let your family enjoy the convenience they want with the added peace-of-mind they need. On-Q/Legrand is changing the definition of home living.

• Cable Type: Cat 6a
• Color: Orange
• Termination: 8P8C, Phosphor Bronze alloy plated with 50 microinches of Gold
• Type: Keystone Insert
• Housing Material: High Impact, Flame-Retardant Plastic
• Connector Type
• End One: RJ45 Female
• End Two: Punchdown
• Flammability Rating: UL 94V-0
• Mounting: Wallplate or Strap
• Wire Gauge: 22 - 24 AWG
• Receptacle Type: RJ45 Female
• Number Of Receptacles: 1
• Input Plug Type: RJ45
• ETL Standard: Yes
• Dimensions: 0.76(H) x 0.665(W) x 1.21(D) inches (19.3 x 16.9 x 30.8 mm)
