Leviton Decora Weather-Resistant 3-Way Switch, 15A/120V
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Details
Use An Outdoor Switch Without A Cover
You will no longer need a cover for your outdoor switch with the Leviton Decora Weather-Resistant Single-Pole Switch, 15A/120V. This unique switch (15 Amp, 120/277 Volt) is the perfect solution for controlling outdoor lighting, motor loads, or any application from your home's exterior because it's completely weather resistant. As a 3-way device, this rocker switch supports installations where two 3-way switches are needed for a single light/load. You'll be able to turn on/off a single light in an outdoor living space or outdoor kitchen from two different areas. This grounded, 3-way AC switch features a body made of UV stabilized thermoplastic material and extra corrosion protection. It provides silent switching action and smooth integration into any outdoor environment such as an outdoor kitchen and bar, patio, pool and spa, shed, gazebo, cabana, and any other outdoor area.
- Weather resistant switch (3-way) doesn't require an outdoor cover supports loads up to 120/277V or 15 Amps
- Actuation occurs with magnets, which prevents water intrusion to the subplate/switch
- NEMA 3R Rated to meet exterior Code (for wet and damp locations)
- Made of UV stabilized thermoplastic construction for wet and damp locations
- Simple installation with side and back wire (wallplate included)
Contents
- Weather Resistant Switch
- Wallplate
- Manual
About Leviton
Leviton is the smart choice, providing the most comprehensive range of solutions to meet the needs of today's residential, commercial and industrial buildings. Leveraging more than a century of experience, Leviton helps customers create sustainable, intelligent environments through its electrical wiring devices, network and data center connectivity solutions, and lighting energy management systems. From switches and receptacles, to daylight harvesting controls, networking systems, and equipment for charging electric vehicles, Leviton solutions help customers achieve savings in energy, time and cost, all while enhancing safety.
Specifications
- Manufacturer Part #: W5601-2W
- UPC: 078477223857
- Switch Type: 3-Way
- Amperage: 15 A
- Color: White
- Device Type: Rocker Switch
- Feature: Weather-Resistant
- Grade: Residential
- Grounding: Grounding
- HP Rating: 1/2HP-120V 2HP-240V-277V
- Max. Amperage: 12 Amp
- Pole: 1
- Voltage: 120/277 VAC
- Actuator Material: Thermoplastic
- Body Material: Thermoplastic
- Strap Material: Steel
- Terminal Accom: Back Wire #10-#14 AWG; Side Wire #12-#14 AWG
- Termination: Side Wire, Back Wire
- Torque Range: 14 – 18 in.-lbs
- Type: Weather-Resistant Rocker Switch
- Certifications: NOM, cULus
- Warranty: 2-Year Limited
