Medilok Combination Lock (SKF-05299NB) — User Manual

User manual for the Medilok combination lock (Item# SKF-05299NB) — a resettable 4-digit combination lock commonly used for medicine cabinets, safes, and lockboxes.

The Lock Is Preset At 0-0-0-0

How to Reset and Use

1. Turn the dial wheels to the preset number 0-0-0-0.
2. Pull up the shackle and turn it away from the hole.
3. Use a screwdriver to turn the reset screw vertically until you reach the "click" point.
4. Set the dial wheels to your own numbers — your new combination is now set. Write down the new combination and keep it in a safe place.
5. Turn the reset screw back to horizontal.
6. After setting your own numbers, slide up the side lid to store the key in the compartment.
7. Always have the rubber side (back side) facing you before placing the lock on the object.
8. Turn the lock 180° to close with the front side facing you. Push down the shackle until you hear a "click" sound.
9. Spin the dial wheels to random numbers to lock.

Item#: SKF-05299NB
