VMP 19" Headend Equipment Rack 2 Post Stabilization Kit

Turn a 2-Post Rack Into a 4-Post

Easily convert a two-post equipment rack into a four-post rack by adding the VMP 19" Headend Equipment Rack 2-Post Stabilization Kit. Available in three different heights, these steel expansion posts have standard 10-32 threading and are compatible with select VMP 19-inch 2-post racks (see details below). The two taller sizes (71" and 84") come with side stabilizing bars to help the newly expanded assembly remain upright without risk.

• Steel expansion posts add onto 2-post rack
• Helps stabilize the equipment rack
• Standard 10-32 threading in expansion posts
• Powder coat finish resists static/current flow

Compatible Racks

• 48" Kit: Rack Model ER-148
• 71" Kit: Rack Model ER-1
• 84" Kit: Rack Model ER-184

IMPORTANT NOTE: VMP products are not available to ship outside the U.S. Please contact VMP directly for international orders.

Install With Confidence

VMP mounting systems hang easily from walls or ceilings and are specially designed for maximum tilt and swivel capacity. This flexibility and rotating capability creates easy viewing from any angle. VMP mounting systems are manufactured from tempered high grade steel with a scratch resistant powder coat finish. They offer load capacities of up to 300 pounds, adjust to fit most televisions and monitors, and have been vigorously tested for safety. Many models are UL listed for extra safety and durability. VMP mounting systems include everything needed to assemble a complete mount, in one box, and require no special tools.

• Manufacturer Part #:
• 48": ER-148-4PKIT
• 71": ER-1-4PKIT
• 84": ER-184-4PKIT
• Dimensions:
• 48": 20.16(W) x 49.2(H) x 14.65(D) inches
• 71": 20.2(W) x 72.25(H) x 14.7(D) inches
• 84": 20.2(W) x 85.25(H) x 14.7(D) inches
• Weight:
• 48": 13.1 pounds
• 71": 19.8 pounds
• 84": 22.1 pounds
• Warranty: "Forever Warranty"
