Russound D1290 — 12-Channel Premium Digital Amplifier Product Guide
Product guide for the Russound D1290 premium multi-channel Class-D amplifier, up to 12 channels and 90 watts per channel.
Full text manual (for reference)
Product guide for the Russound D1290 — a premium multi-channel Class-D amplifier with up to 12 channels, 90 watts per channel, and flexible zone configuration.
Overview
The D1290 low-profile amplifier is perfect for driving premium home theater speakers for optimum movie/TV sound, or for powering multiple speakers throughout the home for music. Russound amplifiers are a go-to choice for audio specialists due to their performance, reliability, and value, and the D1290 extends that legacy with a new premium industrial design suited to a shelf or 19" rack.
Key Features
- Powerful Class-D amplifiers with up to 12 channels and up to 90 watts per channel; inputs are bridgeable for even more power when needed.
- 3 input options per channel: 2 bus inputs and 1 dedicated line input for source flexibility.
- Configurable audio filters: Full Range, Low Pass (20Hz–160Hz), or High Pass (80Hz–20kHz).
- 3 turn-on modes: Always On, Signal Sensing, or 12V Trigger Control.
- Rack-mountable, low-profile 1U form factor — ideal for larger spaces and outdoor areas.
- 2.66 ohm stable — powers up to 3 pairs of 8-ohm speakers per zone.
What's in the Box
- D1290 amplifier
- 6-foot power cord
- Set of removable 4-pin speaker connectors
- Set of rack mount ears with screws
- Owner's Manual
Front/Rear Panel Controls
- Dual Bus Inputs — allows up to 2 different audio sources to be shared among any of the amplifier's zones.
- Dedicated Zone Input — provides a dedicated audio source to each zone.
- Level Gain Adjustment — allows a gain adjustment for every zone.
- Zone Input Selector — configures each zone to use Bus Input A, Bus Input B, or the dedicated Line In.
- Audio Filter Setting Switch — Low Pass (LP), High Pass (HP), or Full-Range (Full) per zone.
- Stereo/Bridged Mode Switch — set to Bridged when bridging a zone's channels into a single mono zone (speaker wiring must be reconfigured per the owner's manual).
- Speaker Connection — removable screw-down speaker selectors accept up to 12 AWG wire.
- Turn-on Mode Switch — Always On, Auto-Sensing, or 12V (for use with the 12V trigger input).
- 12V Trigger In/Out — enables automated turn-on/off via a 12V DC trigger; set the Turn-On Mode Switch to 12V when using this.
Application Example: Adding Extra Speakers
For a home theater setup, feed the 11-channel outputs of a home theater pre-amplifier into the D1290: set in-ceiling speaker zones to Full Range and subwoofer zones to Low Pass.
Specifications
| Spec | Value |
|---|---|
| Number of Channels | 12 |
| Filter Options | High Pass, Low Pass, Full Range |
| Power Output – 4Ω | 90W/channel, 1kHz, one zone driven |
| Power Output – 8Ω | 45W/channel, 1kHz, one zone driven |
| Power Output – 8Ω Bridged | 180W, 1kHz, one zone driven |
| Frequency Response | Full: 20Hz–20kHz; LP: 20Hz–160Hz; HP: 80Hz–20kHz (±3dB at 1W into 4 or 8Ω) |
| Input Sensitivity | 4Ω: 620mV for 90W @ 1kHz; 8Ω: 690mV for 45W @ 1kHz |
| Input Impedance | >22k ohms line input |
| Signal to Noise Ratio | >90dB A-weighted (4Ω); >96dB A-weighted (8Ω) |
| Trigger Input/Output | 12V, Global |
| Line Inputs | Selectable: Bus A, Bus B, Zone |
| Speaker Connectors | Detachable screw-down, up to 12 gauge |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Power Requirements (NA) | 115-120VAC, 60Hz (800W max) |
| Power Requirements (Intl -i) | 220-240VAC, 50Hz (800W max) |
| Standby Power | Less than 0.5W |
| Product Dimensions | 17.125" (W) x 1.75" (H) x 9.75" (D) — 43.5 x 4.4 x 24.8 cm |
| Product Weight | 9 lbs (4.1 kg) |
| Limited Warranty | 2 Years |
