Intrasonic JA-BT-VC Bluetooth Volume Control — Specifications

Specification sheet for the Intrasonic Technology JA-BT-VC Bluetooth Volume Control — an in-wall volume control with a built-in Bluetooth 3.0+EDR stereo receiver, letting you stream audio wirelessly to existing in-wall/in-ceiling speaker wiring.

Specifications

• Bluetooth: 3.0+EDR stereo module, at least 30 feet of range (unobstructed)
• High-efficiency 30W x 2 Class D amplifier
• Frequency range: 20 Hz – 20 kHz
• Stereo input: 3.5mm audio jack
• Easy installation and BT pairing; custom name programming (Android only)
• Uses existing 16-gauge speaker wire
• Requires an approved AC-DC power cord, 24V / 3A minimum for rated power output (NOT included)
• Can daisy-chain up to 2 volume controls (must use a different, higher-rated PSU: 24V-5A, for daisy-chained setups)

Wiring Diagram

The diagram below shows a typical two-zone setup: one JA-BT-VC receives power from a JA-BT-PS power supply and drives a pair of EX-C80II ceiling speakers, while its DC 24V output daisy-chains to a second JA-BT-VC driving a pair of I30W in-wall speakers over Bluetooth.

About Intrasonic Technology

Intrasonic Technology, headquartered in Dallas, TX, manufactures full-featured, easy-to-use music distribution and intercom systems. Their product line includes Music Distribution and Intercom Systems, Video Door Intercom Systems, and a wide variety of ceiling, in-wall, and mini-cube audio speakers and accessories.
