  • Speaker Wire, 14AWG, 2C, Direct Burial, OFC Shielded, 500 Ft.

    WR142SHDB05

    Notify me when this product is available:

    Cable for High-End Audio Installations

    This outdoor Speaker Wire (14AWG, 2C, Direct Burial, OFC Shielded, 500') offers high strand count and has insulated oxygen-free bare copper conductors in an LLDPE jacket for high-end speaker installations. Made for direct burial, the wire features waterproof aluminum foil shielding with a drain wire. It includes the SCP Cable Labeling System for easy identification, and comes in spools of 500 feet.

    • AWG (American Wire Gauge): 14
    • Conductors: 2 (Red and Black for + and -)
    • Jacket Color: Black
    • Package: Spool
    • Applications: High-end professional audio transmissions. Direct burial.

    NOTICE: This part is a heavy/dimensional product; it is not eligible for free shipping. Wire products are not returnable.

    Quality Installation

    • Manufacturer Part #: 14/2SHDB-500
    • Marking: STRUCTURED CABLE PRODUCTS – – – P/N 14/2SH-DB – – – 2 COND 14 AWG STRANDED SHIELDED PE JKT CMX OUTDOOR / DIRECT BURIAL — CE EU RoHS EC ZONE/DEVICE A B C D E 0 1 3 4 5 6 7 8 9 XXXXFT
    • Regulatory: UL 444, UL 13, NEC Article 760, NEC Article 725 EU RoHS 2011/65/EU Compliant
    • Application: Speaker Cable

    Construction Characteristics

    Conductor

    • Material: Stranded Bare Copper
    • Size: 14AWG X 2C (2.11mm2)
    • Construction: 105/0.16mm (0.0063 inch) ±0.004mm

    Insulation

    • Material: PVC
    • Min. Thickness: 0.33mm (0.0130 inch)
    • Avg. Thickness: 0.36mm (0.0142 inch)
