  • Communication Security Wire, 18AWG, 6C, Direct Burial, Shielded with Drain, 1,000 Ft.

    WR186SHDB

    Notify me when this product is available:

    Direct Burial Cable For Security & Audio Installations

    This outdoor Communication Security Wire (18AWG, 6C, Direct Burial, Shielded with Drain, 1,000') has six insulated stranded bare copper conductors in a Linear Low-Density Polyethylene (LLDPE) jacket for outdoor security installations.

    • AWG (American Wire Gauge): 18
    • Conductors: 6 (Black, Red, White, Green, Blue, Brown)
    • Jacket Color: Black
    • Package: Spool
    • Applications: Security, Speaker, Audio, Alarm, HVAC, Access Control, Card Access, Irrigation Control, CCTV Power and Commercial Applications.

    Made for direct burial, the cable features waterproof construction with water-blocking PE tape. The wire's six conductors are shielded with overall AL foil/mylar and insulated by PVC within an LLDPE jacket. The cable also includes a tinned copper drai

    • Manufacturer Part #: 18/6SH-DB
    • Marking: STRUCTURED CABLE PRODUCTS ——— P/N 18/6SH-DB ——— 6 COND 18 AWG STRANDED SHIELDED PE JKT CMX OUTDOOR / DIRECT BURIAL —— CE EU RoHS EC ZONE/DEVICE A B C D E 0 1 2 3 4 5 6 7 8 9 XXXXFT
    • Standards: UL 444; NEC Article 760 & NEC Article 725; CE, EU, RoHS, EC

    Construction Characteristics

    Conductor

    • Material: Stranded Bare Copper
    • Size: 18AWG X 6C
    • Construction: 16/0.254 ±0.004mm

    Insulation

    • Material: PVC
    • Min. Thickness: 0.24mm
    • Avg. Thickness: 0.27mm
    • Diameter: 1.70 ±0.05mm
    • Colors: Black & Red & White & Green &amp
