    Home / Somfy Systems / Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS
    Irismo 35 (Mini DC) RTS

    Irismo 35 (Mini DC) RTS

    SO1003004

    $550.95

    Notify me when this product is available:

    WireFree, Plug-and-Play Drapery Motor

    Add subtle and helpful remote control of your sliding curtain or drapes with the Somfy Irismo 35 (Mini DC) RTS Drapery Motor. This drapery motor allows you to open/close curtains up to 32ft long using a Somfy RTS remote control device, through the Somfy myLink mobile app, or with a short tug of the curtain. This drapery motor includes a touch motion feature that activates the motor with a slight pull on the curtain. The motor is powered via an included power cord that is long enough for it to easily connect to the drapery's rail.

    Works with Alexa-Enabled Controller Badge. Requires Alexa-Enabled Controller. Simply login to your Amazon account through the device app interface. Your device is then instantly available within the Alexa app.

    • Drapery
    • Manufacturer Part #: 1003004
    • Power Supply: 24V DC (included)
    • Amperage: 2A
    • Average Linear Speed: 4.9 in./s – 7.86 in./s (12.5 cm/s to 20 cm/s)
    • Power consumption:< 3 W
    • Power cable type: 4 M (13.2 ft.)
    • Control connector type: RJ12
    • DCT control circuit voltage: 5V DC
    • Motor sound level:< 44 dBA
    • Track maximum length: 32 ft. (9.7 m)
    • Maximum number of junctions: 2
    • Minimum bending radius: 11.8 in. (30 cm)
    • Minimum curving radius: 118 in. (300 cm)
    • Side opening max weight: 77 lbs. (35 kg)
    • Center opening max weight: 77 lbs. (35 kg)
    • Tandem alternative: 154 lbs. (70 kg)
    • Certifications:

    »Somfy 1003004 Irismo 35 Mini DC RTS Drapery Motor Spec Sheet (.pdf)»Somfy 1003004 Irismo 35 Mini DC RTS Drapery Motor Installation Manual (.pdf)
