  • Leviton Wall Switch Occupancy Sensor, 800W/120V

    Color
    Gray
    Ivory
    Light Almond
    White

    Notify me when this product is available:

    Single Pole (One Location) Or Multi-Location

    The Leviton Decora Wall Switch Passive Infrared (PIR) Occupancy Sensor is used to provide automatic lighting control for energy savings and convenience in a variety of commercial applications, including: Small offices, Conference rooms, Lounges, and Class rooms.

    This Wall Switch Occupancy Sensor can be used for automatic switching of incandescent lamps and fluorescent and low-voltage lighting with electronic or magnetic ballasts. The unit also features a manual override switch that can be used to keep lights OFF while an area is occupied, which may be desired in conference rooms and other areas during slide or film presentations. The Wall Switch installs in place of a single-pole wall switch and fits in a standard wall box.

    NOTE: Requires ground connection.

    Leviton Lighting Controls

    • Switch Type: Single-Pole
    • Adjustment: Manual
    • Technology: Passive Infrared
    • Pattern Degrees: 180
    • Coverage Range Sq. Ft.: 2100
    • Time Adjustment: 30s-20m
    • Load Rating: 800W@120V INC 1200VA@120V 2700VA@277V FL
    • Voltage: 120/277 Volt AC 60Hz
    • Wiring Neutral / Ground: Ground Required
    • Photo Cell: Ambient Override ON
    • Wallplate: Order Separately
    • Color: White, Gray, Light Almond, Ivory
    • Standards and Certifications: UL/CSA
    • Code Compliance: California Title 24
