  • 2GIG Super Switch Wireless Takeover Module

    LN2GIGTAKE345

    Notify me when this product is available:

    Add Hardwired Zones to GoControl

    You can integrate a third-party hardwired security system into your GoControl system with the 2GIG Super Switch Wireless Takeover Module. The module connects to a third-party 12-volt control panel and converts signals from your hardwired zones/devices into wireless signals, which are then transmitted to the GoControl panel. The converted zones can then be managed and monitored through your GoControl system.

    • Converts 8 hardwired zones into 8 wireless zones
    • Works with an existing 12-volt control panel
    • Wireless range up to 350 feet from GoControl panel
    • Easy to install with included mounting hardware

    The Super Switch Wireless Takeover Module mounts near the third-party control panel with the included hardware. It can also be powered by the third-party panel. The module supports up to eight hardwired zones total, and all zones act as supervised wireless zones.

    • Manufacturer Part #: 2GIG-TAKE-345
    • Wireless Signal Range: 350 feet, open air, with 2GIG Wireless Control Panel
    • Code Outputs: For each of 8 serialized zones: Fault; Restore; Tamper; Low Battery
    • Transmitter Frequency: 345.000 MHz (crystal controlled)
    • Transmitter Frequency Tolerance: ±15kHz
    • Transmitter Bandwidth: 24kHz
    • Modulation Type: Amplitude Shift Keying-On/Off Keying (ASK-OOK)
    • Unique ID Codes: Over one million different code combinations
    • Supervisory Interval: 70 minutes
    • Peak Field Strength: Typical 50,000 uV/m at 3m
    • Dimensions: 3.54(L) x 2.56(W) x 1.13(H) inches (9.0 x 6.5 x 2.9 cm)
    • Weight: 2.85 ounces (80.8 g)
    • Housing Material: ABS Plastic
    • C
