Yale Double Cylinder Deadbolt

SKU: YAD982N01

Please Select Option To View Availability

$41.95

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Details

Enhance Security For Doors With Glass Panels Or Near Windows

Enhance the security at your home or property with the Yale Double Cylinder Deadbolt. This deadbolt fits standard doors and works with both inswing and outswing doors. As a double cylinder deadbolt, you'll be able to add maximum security to a door on your property since a single key is needed to unlock the door from both the inside and outside. If your door has a glass panel or is near a window, this deadbolt prevents intruders from reaching in and unlocking the door from the inside after breaking the glass.

  • Great for adding maximum security to a door with glass panels or a window nearby
  • Fits standard doors and works with inswing and outswing doors
  • Adjustable latch, concealed screws, and easily installs with just one tool
  • Lifetime limited warranty for mechanical and finish
  • Part of the YH Collection

Contents

  • Double Cylinder Deadbolt
  • Mounting Hardware
  • Instruction Manual

Yale: Simpler & More Secure

Yale focuses on making home security simple, secure, and easily accessible for any consumer. They are committed to designing products and services that allow anyone to monitor and manage entry into the home from wherever they are, while keeping intruders out. They've created a thoughtful system of products and services that are easy to use, aesthetically stylish, and completely reliable. Yale products make life simpler and more secure.

Specifications

  • Manufacturer Part #:
    • D982N01: Satin Nickel
  • UPC:
    • D982N01: 081023185073
  • Grade: Grade 2: A156.36 ANSI/BHMA
  • Door Thickness: 1-3/8" to 1-3/4"
  • Edge Bore: 1"
  • Backset: 2-3/8" or 2 3/4"
  • Face Bore: 2-1/8"
  • Cylinder: 6 Pin Cylinder
  • Keyway1: KW-1 Compatible
  • Latch: Adjustable
  • Latch Front: RC (Round Corner)
  • Strike: 2 1/4" Full Lip RC (Round Corner)
  • Strike Front: RC (Round Corner)
  • Handing: Reversible
  • Operating Temperature:
    • Outside: -22 F to 140 F (-30°C to 60°C)
    • Inside: 5 F to 158 F (-15°C to 70°C)
  • Dimensions:
    • Exterior: 11/16" L x 2-9/16" W x 3-9/16" H (17 x 51 x 76mm)
    • Interior: 2-1/8" L x 3" W x 6-7/8" H (51 x 76 x 152mm)
  • Approvals: A156.2 Series 4000, ANSI/BHMA Grade 2
  • Warranty: Lifetime Limited for Finish/Mechanical
