VSSL SX Series Native Streaming Audio Speaker

Start or Complete a 5.1 Wireless Audio Streaming System

Add a high quality wireless audio streaming speaker to your home with the VSSL SX Series Native Streaming Audio Speaker! This Wi-Fi compatible audio streaming speaker provides Hi-Res 24-BIT/192 KHZ to an audio zone as either a standalone speaker, as part of a pair of SX Speakers, or as part of a 5.1 wireless stereo surround sound system when paired with the SX Subwoofer and SX Soundbar (each sold separately). The Speaker's wide dispersion Balanced Mode Radiators (BMR) drivers and 4" active down-firing woofer provides a balanced audio output for an immersive sound experience in any situation. If two SX Speakers are set up within the same audio zone, they act as left and right channels for a single audio output.

Play audio directly from your wireless streaming device via Apple AirPlay, Chromecast, Spotify Connect or through a wired Ethernet, optical, or HDMI ARC connection. The SX Speaker uses Native Streaming™ technology which enables you to select where to play your preferred audio from your favorite mobile apps on your smartphone or tablet without having to switch between multiple apps or remote controls. You can even command the SX Speaker with Alexa or Google Assistant.

• Wi-Fi compatible streaming audio speaker delivers hi-res audio as a single speaker or when paired with other SX devices
• Premium 3" BMR Full Range Driver and 4" Active Down-firing Woofer
• Emits stereo audio alone, or left /right channel audio when paired with a second SX Speaker
• Wirelessly syncs with the SXSUB and SXSBAR to create a wireless 5.1 Surround Sound System, each sold separately
• Native Streaming™ via AirPlay 2, Chromecast, and Spotify Connect
• Dolby Digital Certified for theater quality sound at home
• Room Correction dynamically tunes the soundbar to the unique acoustics of the room the speaker is installed in
• Voice control compatible with Siri and Google Assistant

Native Streaming – The New Way to Play Music

VSSL's products utilize a revolutionary streaming technology known as Native Streaming™. Native Streaming allows you to easily command your home audio by controlling the selected zones and volume control through your preferred music or audio playing app. This means you can play music from Spotify, Pandora, or YouTube, select where in your home you wish to hear it, and adjust volume levels without leaving the selected app or using a physical remote control or third-party app. This gives you a seamless and simple home audio experience unlike any other.

After initial setup using the Google Home and VSSL apps, all you have to do is connect to your home Wi-Fi, open your favorite audio app, choose which zone to play in, and your music will immediately begin playing. You don't have to open those two apps again except for audio equalizing and reconfiguring zones. No device syncing like with Bluetooth, and no login ID or passwords necessary, aside from your home Wi-Fi password.

Convenient, Advanced Controls Through the VSSL App

Use the VSSL app to set and adjust audio quality, volume settings, zone configuration, and page announcements with recorded audio. You can set volume limits for individual or all zones, adjust EQ settings, and mirror any preferred settings across other selected zones or for the whole system. The VSSL app also allows you to record one-time audio messages that you can send to individual or multiple zones. Tell your kids to come down for dinner, or ask your family to bring up your laundry through your home audio system.

With multiple VSSL products or pre-existing audio systems, you can create pre-set groups that are separate from the normal zones. These groups, or party zones, allow you to select multiple zones to play audio in one easy button press. These party groups don't overwrite your existing audio zones, so you don't have to worry about resetting your original zones once the party is over.

Installation Details

The SX Speaker can be placed on a level surface or wall mounted (¼"-20 Thread Wall Mount sold separately). The Speaker connects to your Internet via 2.4GHz Wi-Fi or Ethernet connection. The Speaker can automatically sync with other SX Series devices and VSSL Streaming Amplifiers on the same Internet network via Wi-Fi or Ethernet. SX Series Subwoofers connect to other SX Series devices via Wi-Fi only.

Contents

• SX Speaker
• Power Supply

Notes

• 1/4"-20 Thread Wall Mount sold separately.
• SX Speaker is sold individually. For LR stereo audio, a pair of SX Speakers is required.
• Native Streaming devices must be connected to the same Internet network in order to synchronize and operate together.
• SX Series devices and your selected wireless audio source must be on the same Wi-Fi network in order to stream audio.
• SX Series Subwoofers connect to other SX Series devices via Wi-Fi only.

IMPORTANT NOTE: VSSL products are not available to ship outside the U.S.

Set Your Music Free With VSSL

VSSL creates premium wireless audio products that are easy to use and enjoyable for people of all ages. Their cutting-edge Native Streaming™ technology delivers all of your music to your fingertips, no third-party controllers or apps necessary. VSSL is the only audio company that uses Native Streaming™, and that's why custom installers and homeowners choose VSSL over any other system to play music throughout their home or office. Native Streaming™, enables listeners to use apps they already know and love, to play music directly from their device to any room.

• Manufacturer Part #: SXSPKR
• UPC: 865432000291
• Speakers: Wide dispersion BMR
• Woofers: 4" Active down-firing
• Stereo Pair: Turn two speakers into separate left and right channel speakers
• Home Theater: Add two SX Speakers as surrounds to an SX soundbar
• Stream: Compatible with AirPlay 2. Google Cast, and Spotify Connect
• Voice: Compatible with Apple Siri and Google Assistant
• Wireless Connectivity: Connects to Wi-Fi network with any 802.11 a/b/g/n, 2.4 or 5GHz broadcast-capable router
• Equalization: Advanced EQ settings
• Ethernet Ports: (2) 10/100 Mbps Ethernet ports (optional)
• Room Correction: Dynamically tunes the soundbar to the unique acoustics of the room area (iOS device required)
• Power Supply: Auto-switching 100-240V ~50-60Hz 2 A AC universal input
• Weight: 4.6lbs
• Dimensions (HxWxD): 7.95" x 5.75" x 6" (202mm x 145mm x 149mm)
• Operating Temperature: 32° to 104°F (0°to 40° C)
• Multiple Orientations: Tabletop or wall mounted with 0.25" -20 thread universal mount

»VSSL SX Series Spec Sheet (.pdf)
»VSSL SXSPKR SX Series Native Streaming Audio Speaker User Manual (.pdf)
