Russound 8-Channel Digital Amplifier
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Details
Efficient High Power Sound From A 8-Channel Amplifier
Improve the reach and overall quality of your home audio system with the Russound 8-Channel Digital Amplifier. This digital audio amplifier supports up to 4 paired zones at up to 90 Watts per channel in order to provide optimal sound quality for nearly any audio source or any sized audio system. As a part of Russound's D-Series of amplifiers, the D890 offers customizable audio options to complement the capabilities of your speaker setups and support any level of audio quality and volume from connected sources. The D890 can support up to 8 audio sources: 2 via dual bus inputs that can be played across all or a selected number of zones, while each individual zone may accept its own dedicated line level audio source to increase the amount of options to play throughout your system. Additionally, each zone's audio settings can be individually configured to accommodate the capabilities of connected speakers, or bridged together into mono zones or to share power with more powerful audio outputs.
- 4 zone, 8-channel amplifier arranged in stereo pairs for custom configurations for each zone
- 90 watts per channel into 4 ohms and 45 watts per channel into 8 ohms
- Supports up to 8 audio inputs: 2 dual bus inputs and 1 per each zone
- Each zone can be independently configured and switch between connected audio sources
- Zones can be bridged for creating flexible power configurations
- Compatible with Russound volume controls and speakers
- Can be rack mounted using the included rack-mount ears and hardware
Installation Details
The D890 Digital Amplifier can be rack mounted into a standard media cabinet filling in only a single rack unit with included hardware. The Amplifier can also be placed onto a desktop surface.
Contents
- D890 Digital Amplifier, 8-Channel
- 6 Ft. Power Cord
- Set of 4 Removable Speaker Connectors
- Set of Rack Mount Ears
- Manual
Russound Brings Engineered Innovation and Extraordinary Sound
The Russound name is synonymous with audio quality around the world. Russound delivers a complete range of multiroom audio systems, source equipment, volume controls, amplifiers, loudspeakers and intercom systems. Every audio device from Russound has been manufactured to fulfill the ideal listening experience of any user – from background music listening to premium performance in your favorite listening areas at home. Russound remains dedicated to providing its dealers and customers with the right products for their desired audio needs.
Specifications
- Manufacturer Part #: D890
- UPC: 612934853906
- Amplifier Channels: 8 channels 4 independent zones
- Bridge: Yes
- Filter Options: High Pass, Low Pass, Full Range
- Power Output:
- 4 Ohms: 90W /Channel, 1kHz, One Zone Driven
- 8 Ohms: 45W /Channel, 1kHz, One Zone Driven
- 8 Ohms Bridged: 180W, 1kHz One Zone Driven
- Frequency Response: 20Hz to 20kHz ±3dB at 1W output into 4 or 8 Ohms
- Input Sensitivity:
- 620 mV for 90W @ 1kHz 4 Ohm One Zone
- 690 mV for 45W @ 1kHz 8 Ohm One Zone
- Fuse Rating: 6.3A, 250V FA
- Input Impedance: >22k Ohms Line Input
- Signal-to-Noise Ratio: >90dB A-weighted
- Trigger Inputs/Outputs: 12V, Global
- Volume Gain Adjustment: By Zone
- Line Inputs: Selectable: Bus A, Bus B, Zone
- Speaker Connectors: Detachable Screw-down, up to 12 Gauge
- Operating Temperature: -32° to 104°F (0° to 40°C)
- Operating Altitude: 0 to 9,843 feet (3000m)
- Minimum Impedance: Stereo Mode 4 Ohms, Bridge Mode 8 Ohms
- Power Requirements:
- North American Model: 115-120VAC, 60Hz (600W Max)
- International Model (D890i):220-240VAC, 50Hz (600W Max)
- Power Connector: IEC C14
- Standby Power: Less Than 0.5W
- Dimensions: 17.125(W) x 1.75 (H) x 9.75 (D) inches (43.5 x 4.4 x 24.8 cm)
- Weight: 9 lbs (4.1 kg)
- Shipping Dimensions: 20.2 (W) x 4.9 (H) x 14.3 (D) inches (51.33 x 12.5 x 36.3 cm)
- Shipping Weight: 11.8 lbs (5.3kg)
- Warranty: 2-Year Limited
