Leviton eXtreme High Flex Cat6 Patch Cord, 1'

SKU: LV6H4601x

Please Select Option To View Availability

$12.11 to $15.95

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Details

Add a Short Extension to Your Local Network

Leviton eXtreme® High Flex Cat 6 Patch Cord, 1 ft. is a 250MHz, 24 AWG Ethernet patch cable capable of 1 Gigabit Ethernet speeds. The cable features a 28-gauge, unshielded, twisted-pair, stranded conductor construction with a standard 8-position modular plug on both ends.

  • Power over Ethernet (PoE and PoE+) compatible
  • Provides connectivity for Cat 6 / 1-Gigabit applications including high-density switches, routers, and other electronics

About Leviton

Leviton is the smart choice, providing the most comprehensive range of solutions to meet the needs of today's residential, commercial and industrial buildings. Leveraging more than a century of experience, Leviton helps customers create sustainable, intelligent environments through its electrical wiring devices, network and data center connectivity solutions, and lighting energy management systems. From switches and receptacles, to daylight harvesting controls, networking systems, and equipment for charging electric vehicles, Leviton solutions help customers achieve savings in energy, time and cost, all while enhancing safety.

Specifications

  • Manufacturer Part #:
    • 6H460-1E: Black
    • 6H460-1L: Blue
    • 6H460-1S: Gray
    • 6H460-1G: Green
    • 6H460-1R: Red
    • 6H460-1W: White
    • 6H460-1Y: Yellow
  • Dimensions: 1-20 feet (0.30 – 6.0m) in 1-foot, (0.3m) increments
  • Materials: 28-gauge, stranded UTP, standard modular non-keyed, 8-position, 8-conductor plug, 94V-0 rated
  • Cable Outer Diameter: 0.15 inches (3.8mm)
  • Bend Radius: 0.60 inches (15.2mm)
  • Temperature (Installation): 0 °C to +50 °C
  • Temperature (Operating): -20 °C to +60 °C
  • STANDARDS & REGULATIONS:
    • ANSI/TIA-568.2-D Cat 6
    • ISO/IEC 11801-1 Class E
    • EN 50173-1 Class E
    • ANSI/TIA-1096-A
    • RoHS 2 compliant
    • UL 444 – CM
    • IEC 60332-1 [1,2] (2004-07), 60754, 61034
    • IEEE 802.3bt PoE: Type 1 (15.4 W) formerly 802.3af,
    • Type 2 (30 W) formerly 802.3at, Type 3 (60 W),
    • Type 4 (90 W)
    • Cisco UPoE (60 W), UPoE+ (90 W)
    • Power over HDBaseT™ PoH (95 W)

Downloads

»Leviton 6H460-XX eXtreme Cat6 High-Flex Patch Cords Spec Sheet (.pdf)
