2GIG Wireless FireFighter Smoke Detector Sensor-Transmitter

Enable Wireless Transmission for Hardwired Smoke Detectors

When your traditional hardwired smoke detectors sound an alarm, make sure your security system receives an alert too by adding the 2GIG Wireless FireFighter Smoke Detector Sensor-Transmitter. This battery-powered sensor mounts up to 6 inches away from a UL-listed smoke detector. It senses when an audible alarm sounds using its built-in microphone, and then transmits a wireless alarm signal to your 2GIG/Honeywell (or other 345MHz) alarm panel.

The sensor can be used with a single hardwired smoke detector or an entire interconnected smoke detection system. When smoke is detected by any or all of your interconnected smoke detectors, your alarm panel will receive an alarm signal. Only one sensor is required to enable wireless communication for an interconnected smoke detection system.

• Converts a hardwired smoke detector to work with wireless alarm panels
• Only one sensor needed for entire interconnected smoke detector system
• Compatible with any 345MHz wireless panel, including 2GIG and Honeywell 5800
• Battery-powered; mounts up to 6 inches away from smoke detector
• Does not impact UL or Fire Marshal approval of existing smoke detectors

The FireFighter Sensor-Transmitter easily mounts to the wall or ceiling with the included hardware. It can be placed up to 6 inches away from the smoke detector as long as its small microphone holes are facing the detector.

Contents

• FireFighter Sensor-Transmitter
• CR123A Battery
• Mounting Hardware

Notes

• Does not detect smoke or issue alarms by itself. Requires use with at least one smoke detector and an alarm panel that receives wireless signals over the 345MHz frequency.
• Non-interconnected smoke detectors require a FireFighter sensor for each smoke detector in the home.

Innovation Drives 2GIG Technology

Now under Nortek's family of Linear products, 2GIG offers intuitive and creative home technology with its premier self-contained, all-in-one security and home automation systems. 2GIG's Go!Control system has become a leading control hub for Z-Wave wireless systems, while 2GIG's Vario Hybrid Security System supports both hardwired and wireless security peripherals to fulfill any security and automation need. With 2GIG in control, users experience technology they never thought possible.

• Manufacturer Part #: 2GIG-FF-345
• Wireless Protocol/Frequency: 2GIG and Honeywell / 345 MHz
• Battery: One (1) 3V lithium CR123A (1550 mAh), included
• Battery Life: 5 years
• Detection Distance: 6 inches (max.)
• Certification: FCC, IC, ETL listed in US and Canada to UL985 standard
