Speco 1080p HD-TVI Digital Video Recorder (DVR), 16-Channel
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Details
Deliver HD AV Signals Through Your Surveillance Network
The Speco 1080p HD-TVI Digital Video Recorder (DVR), 16-Channel brings high-definition surveillance to your home or business without needing to rewire your entire building. This network-connected DVR supports HD recording resolution, enabling up to 16 cameras to capture video up to 4MP at 12fps or 2-3MP at 15fps in H.264 video compression format.
- Records video from up to 16 Speco cameras
- Network software supports 10/100/1000Mbps
- Recording rate up to 4MP at 12fps or 2-3MP at 15fps (H.264 video compression format)
- Supports 2-way audio communication
- Built-in S.M.A.R.T. Technology enhances reviewing of recorded footage
- Compatible with PC and Mac systems
The Speco 1080p HD-TVI Digital Video Recorder (DVR), 16-Channel has 2-way audio capabilities, so you can capture audio for up to 16 channels and/or communicate with intruders when a connected motion detector is triggered. Use a microphone (sold separately) to communicate in real-time, or program a pre-recorded message to play upon activation.
Built-In Hard Drive for Convenient Storage
Equipped with a pre-installed hard drive, the DVR stores recorded video and audio locally for convenient access, and employs H.264 compression to offer quick, high-quality recording. Its HDD storage can be also optimized by switching between low- and high-quality streaming during simultaneous "Continuous + Sensor" or "Continuous + Motion" modes.
Easy Access to Footage via Mobile App
View live and stored video from anywhere, anytime through the free mobile app for iOS and Android devices. The unit also features S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology for HDD) for easier review of recorded footage. You can also program recording to initiate automatically upon motion detection, a triggered sensor, or according to your custom schedule.
Quick & Versatile Setup Options
Designed for quick setup and ease of use, the DVR offers "EZ" features that make camera surveillance a breeze.
- EZ Network: for quick set-up on a network
- EZ Camera: quickly discover and install all Speco IP cameras
- EZ Copy: auto copy what you are playing onto a USB flash drive
- EZ Record: quickly set up recording schedules, resolutions and recording type
- EZ Setup: for quick system setup of general settings
- EZ Search: quickly search events from thumbnails
- View on Android, iPad, or iPhone devices
Compatible with both PCs and Macs, the DVR is network accessible via SpecoTech Multi-Client Software, SecureGuard Plus, Web-Viewer, and Speco Player Mobile Viewer. You can enjoy remote monitoring, recording, playback, configuration, software upgrades and PTZ control all via the Internet.
Contents
- DVR, 16 Channel
- Remote Control
- (2) AAA Batteries
- USB Mouse
- Power Adaptor
- Software & Manual CD (PC)
- Quick Setup Guide
- Quick User Guide
Notes
- To preserve signal quality and distance, Speco Technologies recommends using coax with a 100% copper center conductor and at least 95% braided copper shield.
- Unless DNS is properly set, the DDNS and the e-mail features will not work.
- Individual channels can be set with different RESOLUTION, FRAME RATE, and QUALITY.
- Web-Browser is only available for Internet Explorer and Firefox.
IMPORTANT NOTE: Speco Technologies products are not available to ship outside the U.S. Please contact Speco Technologies directly for international orders.
Commercial & Residential Solutions From Speco
Speco Technologies is dedicated to providing the highest quality residential and commercial sound, security, CCTV closed circuit video and electronic accessories. Contractors, installers, builders, engineers, architects and homeowners rely on Speco products to satisfy both their commercial and residential needs.
Specifications
- Manufacturer Part #:
- 2TB: D16VX2TB
- 3TB: D16VX3TB
- 4TB: D16VX4TB
- 6TB: D16VX6TB
- 8TB: D16VX8TB
- 10TB: D16VX10TB
- Warranty: 5-Year Limited
Video
- Input:
- Camera Types:
- 960H
- HD-TVI: 1, 2, 3, 4 MP
- Output:
- Main Monitor: VGA and HDMI (Max. 4K, 3840x2160)
- CVBS or SPOT (Selectable)
Audio
- Input: 4 lines
- Output: 1 line
- Audio Codec: G.711
Alarm
- Sensor Input: 4 or 16 with Sensor Box
- Alarm Output: 1
Serial
- RS-485: 1
Live
- Frame Rate with 4MP Cameras: 15fps/channel
- Frame Rate with 3MP Cameras: 18fps/channel
- Frame Rate with 2MP Cameras: 30fps/channel
Recording
- Compression: H.264
- Local Resolution & Frame Rate:
- 2688x1520 (4MP): 12fps/channel
- 2304x1296 (3MP): 15fps/channel
- 1920x1080 (2MP): 15fps/channel
- Recording Quality Grade: 5 Levels
- Recording Mode: Smart/Continuous/Motion/Sensor/Schedule/Manual
- Pre-Recording: Max. 20 minutes
- Post Recording: Max. 60 seconds
Playback
- Search: EZ Search, Motion Search, Date/Time, Event, Archive, Log
- Multi-Decoding: 1, 4, 9, 16
- Playback Speed: x0.25, x0.5, x2, x4, x8, x16, x32, x64
Backup
- Media: USB Drive, External HDD, Network
- Format: BMP, AVI, Proprietary Format and EXE
- Huge Backup: Yes (Max. 24 hours)
Storage
- HDD:
- Capacity of 1 HDD: 10TB
- Internal HDDs: Max. 4 each (RAID 1/5/10)
- USB:
- Front: 1
- Rear: 1
User I/F
- Input Method: Front Buttons, IR, Mouse, Keyboard Controller
Network
- Interface: 10/100/1000 Base-TX
- Dynamic DNS: Yes (Free DDNS)
- Dual Streaming: Yes
Network Access
- 3G Mobile: iPad/iPhone/Android
- Web Viewer: Windows (IE, Firefox)
- PC Client: Single/Multi Client and SecureGuard VMS
- MAC Client: Speco Client for MAC and SecureGuard® VMS
- Remote Setup and Upgrade: Yes
Features
- Digital Deterrent®: Default + up to 8 custom audio files
- Digital Zoom: Yes
- EZ Zoom: Yes
- DLS (Daylight Savings): Yes
- S.M.A.R.T: Yes
- Internal Beep: Yes
- Multi-Language: Yes
- E-mail Notification: Yes
- SW Upgrade: USB upgrade
- NTP (Network Time Protocol): Yes
- UL Listed: Yes
Power Source
- Power Supply: 12VDC, 6.67A
Temperature
- Operation: 41° F to 104° F (5° C to 40° C)
- Storage: 14° F to 122° F (-10° C to 50° C)
Humidity
- Operation: 20% to 80% (Non-condensing)
Dimensions
- Unit Dimensions: 11.8 (W) x 9.9 (L) x 2.2 (H) inches (300 x 251.5 x 56 mm)
