Channel Vision 1x12 Audio/Video Baseband Distribution Amplifier

SKU: CVVDA12

Huge Savings! (All Sales Final.)

1 available at this price.

$94.99 $145.91

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Details

Expands RCA Output Socket Of A/V Component

The Channel Vision 1x12 Audio/Video Baseband Distribution Amplifier connects to the RCA output of an A/V component to incorporate an audio input and a video input. The input can then be distributed to 12 outputs. Because these A/V cascade outputs feature automatic video impedance, you can rely on high picture quality. It’s an ideal solution for connecting A/V components to multiple zones or RF modulators.

  • Distributes to 12 A/V outputs
  • Built-in clamp circuit
  • High-power output drive stage
  • Gold-plated RCA connectors
  • Space-saving 17-inch chassis

The Distribution Amplifier has a built-in clamp circuit to prevent up/down roll images. It also ensures superior performance with a high-power output drive stage, adjustable video gain, and gold-plated RCA connectors.

Total Package Solution

Channel Vision has been a leading manufacturer of RF video distribution products, structured wiring enclosures and modules, security cameras, high performance audio/video distribution systems since 1993. Channel Vision manufactures a growing list of products designed to make today’s homes more convenient, safe, and innovative. Channel Vision Central – structured wire systems, Aria – multi-room audio distribution, and Channel Vision Technology – home-theater and security products, combine to make Channel Vision a total packaged solution.

Specifications

Technical Details

  • Material: Black brushed aluminum
  • Dimensions: 3-1/8 (H)x 17-1/8(W) x 9-1/2(D) inches

Audio

  • Input Impedance: 20Kohm
  • Output Impedance: 600 ohms
  • Gain: 11dB
  • Freq. Response: 20Hz to 20XHz
  • Max. Input: 5Vp-p
  • Max. Output: 4.5Vp-p(4/7x Load)
  • Power Requirement: AC 110V/60Hz
  • Power Consumption: 5W (Max.)

Video

  • Input Impedance: 1K ohms
  • Output Impedance: 70 Ohms
  • Gain: 6dB
  • Clamp Capability: 60dB
  • Freq. Response: 20Hz to 8MHz
  • Max. Input: 4Vp-p
  • Max. Output: 1.8Vp-p(75ohms load)
