Applied Digital ADICON 2500 SECU-16I I/O Module

Used With Ocelot & Leopard II Controllers

Features sixteen analog inputs. Screw terminals are provided for all connections. Inputs can be 0-5V analog, 4-20 mA sensors, or secure inputs (switches, motion detectors, etc.) RS-485 interface for connection with the ADICON network.

Home Automation With Applied Digital

Applied Digital manufacturers the power and easy-to-use Adicon collection of home controllers, including the Ocelot programmable standalone controller, the Leopard II touchscreen controller, and the Bobcat single point modules. Choose from a series of add-on modules to customize your Adicon controller.

• I/O: 16 Input Channels – Screw Terminals*(1K Shunt or 0-5V 8-bit Analog)
• ADNET: 2 Screw Terminals (up to 14 AWG)
• Power: 2 Screw Terminals (up to 14 AWG)
• Size: 5.5(L) x 3.25(W) x 1.38(H) inches
• Power: 9-16 Volts AC or DC, 200 mA

»Applied Digital ADICON 2500 SECU-16I I/O Module Installation Manual (.pdf)
