Sensaphone FGD-0065 Carbon Monoxide (CO) Sensor

Monitor CO Levels From 0-300 PPM With Your Sensaphone

Carbon monoxide (CO) is a highly toxic gas that has no color or odor. The Sensaphone Carbon Monoxide Sensor allows you to monitor CO levels from 0-300 ppm with any Sensaphone that accepts a 4-20mA input signal. The 1" x .5" LCD displays the PPM and menu parameters.

Contents

• Carbon Dioxide sensor
• Installation instructions

NOTE: The sensor requires a 24 VDC power supply (Part FGD-0053) to operate.

IMPORTANT NOTE: This Sensaphone product is not available to ship outside the U.S.

Sensaphone Remote Monitoring Solutions

Unexpected events happen. But Sensaphone remote monitoring systems are on alert full time to notify you of threatening conditions, so you can respond quickly and prevent costly damages and disruptive downtime. From wireless capabilities to ultra-low temperature tolerant systems, you'll find the right Sensaphone for your monitoring needs. Start protecting your investments today.

• CO Range: 0-300 PPM
• Accuracy: ± 5% PPM
• Operating Temp Range: -4° to 122° F (-20° to 50° C)
• Coverage Area: 50’ radius
• Housing: Black plastic
• Dimensions: 7.2" x 4.9" x 1.7"
• Compatibility: Sensaphone 1400, 1800, 2000, 2800, Express II, SCADA 3000 and WEB600

»Sensaphone FGD-0065 Carbon Monoxide (CO) Sensor Spec Sheet (.pdf)
